Load capacity/rated load(kg) :
1000
Load centre distance(mm) :
500
Fork height,lowered(mm) :
90
Height,mast lowered(mm) :
2085
Max.lift height(mm) :
1600
Height,mast extended(mm) :
2165
Overall lenght(mm) :
1380
Fork dimensions(mm) :
30/100/800(1060)
Width Overall forks(mm) :
200~950/700
Ground clearance,laden,below mast(mm) :
25
Aisle width for pallets 1000×1200 crossways(mm) :
1915
Aisle width for pallets 800×1200 lengthways(mm) :
Turning radius(mm) :
1235
Lift speed,laden/unladen(mm/time) :
25
Lowering speed,laden/unladen(mm/s) :
Manual control
