Load capacity/rated load(kg) :
1000
Load centre distance(mm) :
600
Fork height,lowered(mm) :
90
Height,mast lowered(mm) :
2080
Max.lift height(mm) :
3000
Height,mast extended(mm) :
3420
Overall lenght(mm) :
1655/1705
Fork dimensions(mm) :
61/170/1100(1150)
Width Overall forks(mm) :
580
Ground clearance,laden,below mast(mm) :
25
Aisle width for pallets 1000×1200 crossways(mm) :
2112
Aisle width for pallets 800×1200 lengthways(mm) :
1945
Turning radius(mm) :
1380
Lift speed,laden/unladen(mm/time) :
25
Lowering speed,laden/unladen(mm/s) :
Manual control
