Load capacity/rated load(kg) :
1500
Load centre distance(mm) :
400
Fork height,lowered(mm) :
90
Height,mast lowered(mm) :
2080
Max.lift height(mm) :
1600
Height,mast extended(mm) :
2080
Overall lenght(mm) :
1655/1705
Fork dimensions(mm) :
61/170/1100(1150)
Width Overall forks(mm) :
550
Ground clearance,laden,below mast(mm) :
25
Aisle width for pallets 1000×1200 crossways(mm) :
2112
Aisle width for pallets 800×1200 lengthways(mm) :
1945
Turning radius(mm) :
1380
Lift speed,laden/unladen(mm/time) :
21
Lowering speed,laden/unladen(mm/s) :
Manual control
